  • Superlight

    ×

    8 829 766 059

    Superlight


    Specification
    Colour
    white
    Fixation
    with wall arm
    Light distribution
    asymmetrical
    Beam angle (FWHM)
    57° / 138°
    Light source
    LED 3000 K
    Luminous flux
    1547 lm
    Power
    31 W
    Efficiency
    50 lm/W
    Control
    on / off
    Color Rendering Index cri
    CRI > 70 > 70
    Colour tolerance
    max 2 SDCM
    Service life
    L: 90, B:10
    Download
    • Data sheet PDF
    • Specification text TXT
    • Mounting instructions PDF
    • Luminaire data LDT
    • Luminaire data IES
    • Drawing ai
    • Product photo jpg

    Add accessories to your data sheet with a click.

    128 0 231 960 | white

    Wall plate A (U shaped) aluminum, polyester powder coated, for additional support on unstable surfaces
    Download data sheet

    Superlight 18 W is a well established product offering both economical and uniform illumination of entrances, façades and canopies. The robust knuckle joints allow for flexible orientation of the fixtures.

    Preselection
    Light source
    Fixation
    Colour
    Light distribution
    Color temperature

    24 Products
    •   Part number Description Colour Light distribution Light source Luminous flux Power
    • 8 829 045 0598 829 045 059Superlightblackasymmetrical 57° / 138°LED 4300 K1624 lm31 Won / off
    • 8 829 046 0598 829 046 059Superlightblackasymmetrical 57° / 138°LED 3000 K1547 lm31 Won / off
    • 8 829 055 0598 829 055 059Superlightsilver greyasymmetrical 57° / 138°LED 4300 K1624 lm31 Won / off
    • 8 829 056 0598 829 056 059Superlightsilver greyasymmetrical 57° / 138°LED 3000 K1547 lm31 Won / off
    • 8 829 065 0598 829 065 059Superlightwhiteasymmetrical 57° / 138°LED 4300 K1624 lm31 Won / off
    • 8 829 066 0598 829 066 059Superlightwhiteasymmetrical 57° / 138°LED 3000 K1547 lm31 Won / off
    • 8 829 145 0598 829 145 059Superlightblackasymmetrical 57° / 138°LED 4300 K1624 lm31 Won / off
    • 8 829 146 0598 829 146 059Superlightblackasymmetrical 57° / 138°LED 3000 K1547 lm31 Won / off
    • 8 829 155 0598 829 155 059Superlightsilver greyasymmetrical 57° / 138°LED 4300 K1624 lm31 Won / off
    • 8 829 156 0598 829 156 059Superlightsilver greyasymmetrical 57° / 138°LED 3000 K1547 lm31 Won / off
    • 8 829 165 0598 829 165 059Superlightwhiteasymmetrical 57° / 138°LED 4300 K1624 lm31 Won / off
    • 8 829 166 0598 829 166 059Superlightwhiteasymmetrical 57° / 138°LED 3000 K1547 lm31 Won / off
    • 8 829 745 0598 829 745 059Superlightblackasymmetrical 57° / 138°LED 4300 K1624 lm31 Won / off
    • 8 829 746 0598 829 746 059Superlightblackasymmetrical 57° / 138°LED 3000 K1547 lm31 Won / off
    • 8 829 755 0598 829 755 059Superlightsilver greyasymmetrical 57° / 138°LED 4300 K1624 lm31 Won / off
    • 8 829 756 0598 829 756 059Superlightsilver greyasymmetrical 57° / 138°LED 3000 K1547 lm31 Won / off
    • 8 829 765 0598 829 765 059Superlightwhiteasymmetrical 57° / 138°LED 4300 K1624 lm31 Won / off
    • 8 829 766 0598 829 766 059Superlightwhiteasymmetrical 57° / 138°LED 3000 K1547 lm31 Won / off
    • 8 829 845 0598 829 845 059Superlightblackasymmetrical 57° / 138°LED 4300 K1624 lm31 Won / off
    • 8 829 846 0598 829 846 059Superlightblackasymmetrical 57° / 138°LED 3000 K1547 lm31 Won / off
    • 8 829 855 0598 829 855 059Superlightsilver greyasymmetrical 57° / 138°LED 4300 K1624 lm31 Won / off
    • 8 829 856 0598 829 856 059Superlightsilver greyasymmetrical 57° / 138°LED 3000 K1547 lm31 Won / off
    • 8 829 865 0598 829 865 059Superlightwhiteasymmetrical 57° / 138°LED 4300 K1624 lm31 Won / off
    • 8 829 866 0598 829 866 059Superlightwhiteasymmetrical 57° / 138°LED 3000 K1547 lm31 Won / off
