8 898 041 009

Wall mount luminaire


Specification
Colour
black
Fixation
with joint
Light distribution
wide beam
Beam angle (FWHM)
126° / 124°
Light source
HID
Luminous flux
3800 lm
Power
70 W
Efficiency
41 lm/W
Control
on / off
Download
  • Data sheet PDF
  • Specification text TXT
  • Mounting instructions PDF
  • Luminaire data LDT
  • Luminaire data IES/ZIP
  • Drawing ai
  • Product photo jpg

Add accessories to your data sheet with a click.

128 0 086 940 | black

Corner fixing bracket B aluminum, polyester powder coated, to mount luminaires on 90° corners

128 0 232 940 | black

Wall plate B aluminum, polyester powder coated, for additional support on unstable surfaces

128 0 199 940 | black

Pole top fitter, for 1 luminaire aluminum, polyester powder coated, for 76 mm Ø pole, for one luminaire

128 0 200 940 | black

double pole mount adapter aluminum, polyester powder coated, for 76 mm Ø pole, for two luminaires

128 0 073 940 | black

Pole top fitter, for 3 luminaires aluminum, polyester powder coated, for pole top Ø 76 mm, for three luminaires
Download data sheet

Pole top/wall mount luminaires are used for symmetrical and uniform area lighting. They can be mounted either on a pole or wall and are characterized by their very slim profile. These luminaires are available for compact fluorescent, high pressure sodium lamps and high pressure mercury lamps.

Preselection
Light source
Colour
Light distribution
Light distribution
Control
Power

12 Products
  •   Part number Description Colour Light distribution Light source Luminous flux Power
  • 8 894 041 0098 894 041 009Wall mount luminaireblackwide beam 96° / 95°TC-L 3600 lm60 Won / off
  • 8 894 046 0098 894 046 009Wall mount luminaireblackwide beam 96° / 95°TC-L 24 Won / off
  • 8 894 051 0098 894 051 009Wall mount luminairesilver greywide beam 96° / 95°TC-L 3600 lm60 Won / off
  • 8 894 056 0098 894 056 009Wall mount luminairesilver greywide beam 96° / 95°TC-L 24 Won / off
  • 8 894 061 0098 894 061 009Wall mount luminairewhitewide beam 96° / 95°TC-L 3600 lm60 Won / off
  • 8 894 066 0098 894 066 009Wall mount luminairewhitewide beam 96° / 95°TC-L 24 Won / off
  • 8 897 041 0098 897 041 009Wall mount luminaireblackwide beam 126° / 124°HID 5600 lm70 Won / off
  • 8 897 051 0098 897 051 009Wall mount luminairesilver greywide beam 126° / 124°HID 5600 lm70 Won / off
  • 8 897 061 0098 897 061 009Wall mount luminairewhitewide beam 126° / 124°HID 5600 lm70 Won / off
  • 8 898 041 0098 898 041 009Wall mount luminaireblackwide beam 126° / 124°HID 3800 lm70 Won / off
  • 8 898 051 0098 898 051 009Wall mount luminairesilver greywide beam 126° / 124°HID 3800 lm70 Won / off
  • 8 898 061 0098 898 061 009Wall mount luminairewhitewide beam 126° / 124°HID 3800 lm70 Won / off
